TBT-0705 Bulk Density of laboratory Compacted Asphalt Tester
Request a Quote
Technical Parameters
- Effective volume of water bath: 83L
- Power of refrigeration compressor: 1/4P
- Power of heating element: 1.3kW
- Flow rate of circulation water pump: 10L/min
- Electric balance: max. weight, 15kg; reciprocal sensibility, 0.1kg
- Water bath controlling temperature accuracy: (25±0.5)℃
- Power supply: AC (220V 10%)V, 50Hz
- Maximum power consumption: ≤1600w
- Dimension: 930x750x1150mm
Standard accessories
| No. | Name | Unit | Qty |
| 1 | TBT-0705 Compacted Bituminous Mixtures Density Tester | Set | 1 |
| 2 | High precision electronic balance (including the use of manual, hook and other accessories) | Set | 1 |
| 3 | Electrical control box | Set | 1 |
| 4 | Blue round net | Set | 1 |
| 5 | Blue square net | Set | 1 |
| 6 | Fuse (10A Φ5×20) | Piece | 2 |
| 7 | Drain (inner diameter Φ10, length 3 meters) | Piece | 1 |
| 8 | Specimen tray (when the specimen on the balance disc to weigh we should prevent water droplets into the balance) | Piece | 1 |
| 9 | Tray bracket (placed into the specimen tray, the specimen is above it) | Piece | 1 |
| 10 | Operation manual | Piece | 1 |
| 11 | Temperature control device usage manual | Piece | 1 |
| 12 | Quality certificate | Piece | 1 |
| 13 | Product warranty card | Piece | 1 |
