Bulk Bag Filler

Request a Quote

View All: http://drymix-en.com/2-1-4-bulk-bag-filler.html

Automatic big bag filling system

Speeds between 20-40 bags per/hour

Efficient bulk handling of powders and granular materials is important for industries dealing with large-volume packaging operations. Our bulk bag filler offers a comprehensive solution tailored to simplify and enhance the filling and packaging process of bulk bags (FIBC bags). These bag fillers combine precise electronic weighing, automatic bag release, and integrated dust control, resulting in fast, accurate, and environmentally friendly packaging operations. Filling speed adjustments can be conveniently made by operators, ensuring flexibility according to the unique characteristics of each material.

Applications

Construction Materials: Facilitates packaging of mortar, gypsum, cement, lime, sand, putty powder, and similar materials, simplifying handling, storage, and transport processes.
Chemical Industry: Ideal for bulk packaging and transport of fertilizers, chemical raw materials, and plastic granules, which are often traded by the ton.

Specifications

Weighing range	200-2000kg/bag
Packaging speed	20-40ton/hour
Dynamic weighing accuracy	±0.5%
Power supply	380V 50Hz
Power	8.5kW
Compressed air pressure	0.4-0.8MPa
Air consumption	Approx. 0.6m³/min-8m³/h
Dust removal air volume (m³/h)	800-3000m³/h
Ambient temperature	-10 to 40℃
Relative humidity	≤80%
Bulk bag type	FIBC bag, woven sack, big bag, ton bag
Optional	Storage silo, screw conveyor, belt conveyor, bucket elevator

Features

Equipment customization options are available, enabling precise adaptation to various powder and granular material characteristics and specific production requirements.
An integrated dust extraction system maintains a clean working environment by effectively reducing airborne particles, improving worker safety and comfort.
The electronic weighing system includes a digital calibration panel, automatic tare adjustments, automatic zero calibration, and drop correction, ensuring consistently accurate filling weights.
Packaging speed can be easily adjusted to accommodate different material properties and production demands, providing flexibility and operational efficiency.
