Model
  • KX-SDC-30
Lifting Capacity
  • 3000KG
Features
  • Pallet truck forks are made of high grade carbon structural steel for reliable strength and long-term durability;
  • Adopting high quality pump, Mpa test result shows that the hydraulic pump assembly is featured by no leakage and no deformation;
  • Oilless bearings are fitted onto core movable parts to enhance wear resistance and durability, and prolong the service life of pallet truck;
Technical Data
Model KX-SDC-30
Rated capacity (kg) 3000
Load roller (mm) Φ80/70
Steering wheel (mm) Φ180/50
Min. fork height (mm) 85
Max. fork height (mm) 200
Fork size (mm) 1500/2000/2500/2850
Fork length (mm) 450
Truck height (without tow bar) (mm) 1230
Overall width (mm) 550/685
Overall length (mm) 1870/2370/2870/3220
Net weight/gross weight (kg) 118/138/158/172
