GE288-IIB Raschel Machine

Double needle bar raschel knitting machine for producing faux fur fabrics, plush toys, blankets and apparel fabrics

Applications

Faux fur fabrics, plush toys, blankets and apparel fabrics.

Features
  • Faux fur warp knitting machine uses an oil immersed cam-linkage mechanism and a fixed knock-over comb bar.
  • The spacer fabric warp knitting machine features an easy operation sinker system, allowing automatically adjusting of the distance between knocking over bar, and the ground bar.
  • Raschel warp knitting machine utilizes synchronous belt drive for electronic yarn let-off and electronic fabric take-up.
  • The plush has a pile height of 10-60mm/20-120mm.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E16, E18, E22
  • Number of bars 5 bars
  • Working width 90"/100"/110"
  • Max. speed 850 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE288-I A-90" 3700×6050×3750 22.4 8000 11
GE288-I A-100" 4000×6050×3750 24.2 8500 11
GE288-I A-110" 4350×6050×3750 26.3 9350 11
