GE3238 Raschel Machine (8 bars)

Double needle bar raschel knitting machine for producing faux suede fabrics used in blankets, plush toys and home upholstery

Applications

Faux suede fabrics, eco-friendly air conditioning filter materials, and short, medium, and long plush jacquard fabrics used in apparel textiles, home textiles, filter screens, blankets, plush toys and home upholstery.

Features
  • Faux suede fabric warp knitting machine uses an oil immersed cam-linkage mechanism and 3 fixed ground bars.
  • Raschel warp knitting machine allows for complex jacquard.
  • The textile machinery has functions of electronic yarn let-off and EL pattern drive with electronic guide bar drives.
  • Finished plush products have minimal shedding.
Specifications
  • Needle type Individual latch needle, block latch needle
  • Gauge E16, E18, E22
  • Number of bars 8 bars
  • Distance between knocking-over bar 10-80mm
  • Working width 100"/110"
  • Max. speed 700 rpm
Machine Model Dimensions (L×W×H) Floor Area (m²) Machine Weight (kg) Total Power (kW)
GE3238-100" 3700×6615×3750 24.4 8000 19
GE3238-110" 4350×6615×3750 28.7 9350 20
