Application
The electromagnetic feeder is suitable for the feeding process in ore powder automatic production lines thanks to its simple structure, automatic dosing and quantitative packing. Electromagnetic feeders can be used for the feeding of non-cohesive materials, and they can convey bulk or powder materials to the downstream equipment uniformly and continuously.

Applicable materials
Limestone, granite, gold ore, iron ore, zeolite, pyrite, cement, fly ash, etc.

More Details

Parameters

Model	Trough Size (L×W×H) (mm)	Feeding Size (mm)	Horizontal Feeding Quantity (t/h)	Feeding Quantity (t/h)	Power (kW)	Overall Dimension (L×W×H) (mm)	Weight (kg)
GZ1	600 ×200 × 100	50	5	7	0.06	910×376×485	80
GZ2	800×300×120	50	10	14	0.15	1175 × 608 × 600	165.5
GZ3	900×400×150	75	25	35	0.2	1325×578×675	223
GZ4	1100×500×200	100	50	70	0.45	1616×762×814	462
GZ5	1200×700×250	150	100	140	0.65	1815×840×980	656
GZ6	1600×900×250	200	150	210	1.5	2410×10925×1500	1252
GZ7	1800×1100×250	250	250	350	3	2800×1330×1710	2017
GZ8	2200×1300×300	300	400	560	4	3302×1556×1995	3153
GZ9	2400×1500×300	350	600	840	5.5	3515×1776×2200	3750
GZ10	2500×1800×375		750	1050	4×2	3630×2500×2235	6491
GZ11	2800×2000×375	500	1000	1400	5.5×2	4060×2640×2919	7680
GZ12	3000×2200×400	500	1200	1500	15	5260×2860×2563	8840
GZ13	3200×2500×450		1300	1600	15	6394×3040×2864	9920
GZ14	3500×2500×450	550	1500	1700	18.5	7475×3802×3000	11000

Features

Simple structure, feeding uniformly, continuously, adjustable exciting force
Easy to operate
With eccentric block excitation source, low noise, less electricity consumption, no sprinkling
Prevent from dust with closed mainframe
Feeding speed can be changed at any time
