3-Stage Tankless Under Sink RO Water Filter System (400-1200GPD)

Request a Quote

View All: http://waterfilter-system.com/1-3-1-horizontal-filter-placement.html

Reverse osmosis system with horizontal filter placement design

Filtration SystemCP RO CB
Purified/Drain Ratio2:1
FunctionsZero stale water design ensuring every cup of water fresh and clean
Double dispensing design, meeting the demand of direct drinking and living water
High flow water purification, drinking without waiting
High flow rate, ensuring your drinking freely at any time without waiting
Low operating noise achieved by multi noise reduction technology
Long-lasting cartridge, significantly reducing your cost of using
Free from BPA in the entire water way

This RO water filter system is a kind of conventional water purification system with three separate filters (CP, RO, CB) to deliver purified drinking water. The CP filter consists of PP cotton, a compressed activated carbon block and a second layer of high-precision PP cotton that can remove sand, rust, sediments and odors. And other contaminants like heavy minerals, bacteria and virus would be eliminated by the RO membrane filter with filtration precision of 0.0001um-0.001um. Nothing but insipid water is left after these processes. Therefore we place a CB filtration cartridge that can add minerals essential to people’s health back into water. After that, you would have weak alkaline drinking water.

Model Options

Model AW-RK01

Model AW-RK02

Specifications

RO flow available	400GPD	600GPD	800GPD	1000GPD	1200GPD
Power	60W	80W	100W	130W	150W
Voltage	24V	24V	24V	24V	36V
Purified water flow rate	1.04L/min	1.56L/min	2.08L/min	2.60L/min	3.12L/min
RO permeate: drain	2:1
Filtration stages	4
First filter service life	CP/9-15months
Second filter service life	RO/30-48months
Third filter service life	CB/12-18months
Min. input water pressure	0.1Mpa
Max. input water pressure	0.4Mpa
Inlet water quality	Municipal water
Inlet water temperature	5-38℃
Ambient temperature	4-40℃
Installation	Under the sink
Gross weight	11.7kg		16.0kg
Product size	392135393mm		457135393mm
Carton size	695192465mm		815192495mm
Container (20FT/40GQ/40HQ)	510pcs/1035pcs/1178pcs		405pcs/812pcs/940pcs
The above data is obtained from our laboratory test results. Due to the difference in water quality and water consumption, the replacement cycle of the filter element will be different, depending on the actual use.

Features

Two outlets for dual use, this tankless water filter system has two water circuits to deliver two types of filtered water. The water filtered through CP filter cartridge is used for washing fruits and vegetables, while the water filtered by CP RO CB composite filter is safe to drink.
Specially-designed integrated water circuit effectively prevents water leakage
Fast-flow, fresh and great tasting water perfect for drinking and cooking
Quiet operation with noise level of less than 40dB
Small size of the tankless water filter system saves space in your kitchen
Timely reminding of filter cartridge lifetime to ensure safe and healthy drinking water

Optional Faucet Types

Single outlet faucet
Dual outlet faucet
LED ring faucet
Smart faucet
