Filling System, LY Series
  • Advantages: Both auto and annual operation models are available;
  • Feature: 32-bit dual-core CPU, explosion proof;
  • Applications: Coatings, inks, furniture paints, shoe glues, resins,chemical solvent;
Filling Machine, LY-30AT-ZDX
  • Double head filling
  • Weighing range: 5-30kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 8-16 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 2200x850x1350mm
Filling Machine, LY-30U
  • Single head filling
  • Weighing range: 5-30kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 8-20 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 1000x600x1300mm
Filling Machine, LY-30U-LT
  • Single head filling
  • Weighing range: 0.5-5kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 8-20 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 1300x700x1250mm
Filling Machine, LY-30H
  • Single head filling
  • Weighing range: 0.5-5kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 8-20 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 600x650x1000mm
Filling Machine, LY-30UT
  • Single head filling
  • Weighing range: 0.5-30kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 6-12 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 1500x600x1350mm
Filling Machine, LY-30H2
  • Double head filling
  • Weighing range: 0.5-30kg
  • Divison value: 1g, 2g, 5g, 10g
  • Filling speed: 12-30 barrel/min.
  • Power supply: AC 220V±10%, 50Hz
  • Air supply pressure: 0.5Mpa
  • Dimension: 1100x600x1200mm
