Self-Stacking Spiral Conveyor Belt
Request a Quote
The self-stacking steel conveyor belt achieves counterclockwise or clockwise turning, both of which can complete a full 360 degree turn. The conveyor belt is produced using a numerically controlled machine, and is comprised of the wire mesh, cross rods and chains. The belt is usually constructed with unilateral spirals and made of stainless steel spring steel wire in order to reduce deformation. The metal belt is widely used in stacked spiral conveyors, and can be customized according to customer requirements.
Application
- Freezer Belt;
- Cooling Belt;
- Fermentation heating belt;
- Bakery Belt.
Parameters
| Material | 304 stainless steels |
| Wire diameter (mm) | 1.5, 1.6, 1.7 |
| Spiral pitch (mm) | 6-20 |
| Rod pitch (mm) | 30 |
| Belt width (mm) | 420, 580, 640, 760, 920, 1060 |
| Rod diameter (mm) | 5, 6, 7 |
| Story height (mm) | 60, 80, 100, 120, 140, 180 |
| Belt length | customized |
| Belt edge | welded |
Note: the above are common specifications only, and we offer customization services to meet client requirements.
Characteristics
- The self-stacking steel conveyor belt uses a solid and durable food grade stainless steel.
- The steel conveyor belt features a spiral structure with an outstanding turning performance that achieves a 360 degree turning.
- The conveyor belts feature an excellent ventilation and are easy to clean.
- The surface of the belt is smooth and features stainless steel capable of a high load bearing and high tensile strength bearing performance.
- The dismantling and maintenance of steel conveyor belts are convenient and timesaving, and belt cleaning is easy.
