Blow Bars and Hammers

Request a Quote

View All: http://jhcastingparts.com

Impact Crusher
Impact Crusher

Name: Blow Bar and Hammer
Applicable machine: Impact crusher
Raw materials: High manganese steel, advanced composite material, modified high manganese steel, new type high manganese steel, alloy steel, bimetal composite, austenite wear resistant manganese steel
Applications: The blowbars are our highly wear resistant crusher consumables designed for various kinds of impact crushers. These mining machinery parts are used for the fine and medium fine impact crushing of medium hardness materials such as limestone, furnace slag, coke, coal, etc. in cement, chemical, power, metallurgy and other industries.
Customized or not: Yes
Parts model: 1210, 1315, 1214, 1010
Order quantity: Based on customer's needs

Blow Bars
Blow Bars

Technical Parameters of Applicable Impact Crusher

Models	Specs (mm)	Feeding port (mm)	Max. Feed particle size (mm)	Capacity (t/h)	Power (Kw)	Dimensions (mm)	Weight (t)
PF-0807	ø850×700	400×730	300	15-30	30-45	2210 ×1490 ×2670	8.1
PF-1007	ø1000×700	400×730	300	30-50	37-55	2400 ×1558 ×2660	9.5
PF-1010	ø1000×1050	400×1080	350	50-80	55-75	2400 ×2250 ×2620	12.2
PF-1210	ø1250×1050	400×1080	350	70-120	110-132	2690 ×2338 ×2890	14.9
PF-1214	ø1250×1400	400×1430	350	130-180	132-160	2690 ×2688 ×2890	18.6
PF-1310	ø1300×1050	490×1170	400	80-140	110-160	2780 ×2478 ×2855	16.2
PF-1315	ø1320×1500	860×1520	500	160-250	180-260	3096 ×3273 ×2667	19.3
PF-1415	ø1450×1500	1145×1520	950	220-450	220-315	3745 ×3022 ×3519	27
PF-1520	ø1520×2000	830×2050	700	300-550	315-440	3581 ×3560 ×3265	36.5
