Curtain Wall Panel

Request a Quote

View All: http://rollform-machines.com/1-3-roll-forming-line-for-curtain-wall-panel.html

GZ Roll-Forming offers high quality roll-forming lines with a fully automatic control system for curtain wall panels. Punching, slotting and other function are integrated in-line, meaning there is no need for secondary operations. Other devices can also be equipped upon request to carry out laminating, bending, or discharging.

The product shape, output and other parameters are all set on the touch screen while HMI is achieved with no mechanical adjustments. The PLC, inverter, and other electrical components are imported from Germany and Japan to ensure the roll-forming system’s long-term performance.

Gallery

Technical Parameters

Forming material	0.4- 1.8mm cold/hot-rolled and aluminum alloy metal strip
Forming passes	8- 16
Production speed	6~15m/min
Cut off	Hydraulic cut-to-length
Processing quality	Straightness: L≤2000mm, curvature≤2mm; deflection≤2º No surface wrinkles, bumps, scratches or other defects Cross-section size and hole position meet customer’s requirements or national standards
Remark: Custom design is available according to client’s actual requirements. The data listed above is only for reference.
