YONG-FENG Y80C Side Feed Hose Crimping Machine

YONG-FENG Y80C Side Feed Hose Crimping Machine
YONG-FENG Y80C Side Feed Hose Crimping Machine
YONG-FENG Y80C Side Feed Hose Crimping Machine
YONG-FENG Y80C Side Feed Hose Crimping Machine
Request a Quote

Application
The crimp force of YONG-FENG Y80C side feed hose crimping machine is 800KN, with a crimp range of 4~87mm. YONG-FENG Y80C crimpers are widely used for crimping high-pressure fuel pipes, industrial hoses, hydraulic hoses, medical hoses and water hoses, metal pipes and steel tubes, etc.

Max. inner diameter
Industrial hoses: 1 ¼"
Hoses with 2 braided wires: 1 ¼"
Hoses with 4 spiral wires: 1¼"

Specification
Crimp head material FORGE STEEL
Crimp range 4-87mm
Hose size 1¼", 4SN
Passing diameter 112 100mm
Opening diameter 112mm
Opening 25 100mm
System pressure 31.5Mpa
Crimp force 800KN
Drive 3kw/4kw
Standard voltage Customized
Control Digital CNC with display
Standard dies Customized
Weight 940kg
L x W x H 850*800*1600 mm
Foot pedal Included
Customized special dies Included
Instruction book Included

Material
The oil cylinder cover, oil tank and piston rod are made of 40 chromium, with a surface hardness of HRC26-30 and an operation layer hardness of HRC59-63. The harden layer is 2mm thick. The 40 chromium is high pressure resistant and tear resistant with great impact absorbing and carrying capacity. Therefore, the oil tank and piston rod are more durable.
