Hydraulic Terminal Crimping Machine
Request a Quote
- Constructed with a one-piece ductile cast iron frame, providing durability and stability for consistent crimping operations.
- Equipped with a high-precision encoder to monitor crimping height in real time, ensuring accurate and reliable results.
- Compatible with an external barcode scanner for seamless integration with ERP management systems.
Technical Data
| Model | ||||
| Effective Stroke | 50mm | 50mm | 100mm | 100mm |
| Crimping Range | 2.5-35mm² | 2.5-95mm² | 2.5-180mm² | 2.5-240mm² |
| Dimensions (L×W×H) | 470×390×942mm | 470×390×1022mm | 550×500×1240mm | 550×500×1340mm |
| Weight | 165kg | 180kg | 295kg | 320kg |
| Crimping Capacity | 800-1500 crimps/hr | 800-1500 crimps/hr | 800-1500 crimps/hr | 800-1500 crimps/hr |
| Power | 50W | 50W | 50W | 50W |
| Startup | Manual, foot switch | Manual, foot switch | Manual, foot switch | Manual, foot switch |
| Operation Method | Touch control, automatic adjustment of crimping height | |||
| Control | Oil, electricity, gas | |||
| Crimping Dies | Hexagonal die, square die, B-type die (OTP/2000 type) | |||
Features
-
Stores past crimping data, enabling quality management and traceability for enhanced production oversight.
-
Allows quick switching between different terminal heights, improving production flexibility and reducing setup time.
-
Supports continuous crimping of terminals with varying heights, enhancing complex assembly processes.
-
Network-ready for EMS system integration, enabling centralized production management and monitoring.
