High-voltage Generator
Request a Quote
Description of High-voltage Generator
- Power: 800kw and 1100 kW
- Rated voltage: 6300V and 10500V
- Rated frequency: 50 HZ
- Net weight: 8000Kg, 15000Kg, 20200Kg
- There are three models for customer's choice
Applications
This generator is extensively used in power plant, large scale electrical equipment etc.
Click Here to
Technical Specification of High-voltage Generator
| Model | Diesel engine model | Rated power (kW) | Rated rpm (r/min) | Rated voltage (V) | Rated frequency (Hz) | Overall dimensions (mm) | Net weight (kg) |
| 800GF6 | G12V190ZLD5 | 800 | 1500 | 6300 | 50 | 5925x2040x2678 | 8000 |
| 800GF9 | G12V190ZLD2 | 800 | 1500 | 10500 | 50 | 6500x2200x2800 | 15000 |
| 1100GF | A12V190ZLD | 1100 | 1500 | 6300 | 50 | 6651x2180x2739 | 20200 |
CNPC JICHAI was formed in 1920, we are a prestigious brand in China and is a global leader in internal conbustion engine and generator set manufacturing. Our power solutions are designed to improve your performance and productivity.
