800kW-3000kW Diesel Genset

800kW-3000kW Diesel Genset

DINGBO Power's high voltage diesel generators are engineered for robust performance, featuring large capacities ideal for long-distance power supply. These generators are well-suited for demanding applications such as in metallurgy, industrial sectors, data centers, airports, and ports, where high reliability and superior performance are crucial.

Key Specs
  • Power Range: 1000kVA to 3750kVA (800kW to 3000kW)
  • Voltage Options: Typically 6.3kV, 10kV, 10.5kV, 11kV
  • Engine Options: Includes industry leaders such as Cummins, Yuchai, Baudouin, Weichai, and MTU
  • Alternator Choices: Marathon, Engga, Leroy Somer, Stamford
Features
  • Superior Dynamic Performance: Ensures minimal voltage waveform distortion and high voltage regulation accuracy.
  • Efficient Power Distribution: Structured to support long-distance and high-capacity power distribution efficiently.
  • Operational Efficiency and Longevity: High efficiency and durability extend the lifespan under continuous operation.
  • Grid Connection: Excellent grid-connected functionality ensures reliable integration with existing power systems.
  • Customization: Available in both open skid and containerized configurations to meet specific operational requirements.
Selection table
Genset Model Diesel Generator Set Dimension
Prime Power Standby Power L x W x H( mm )
kW kVA kW kVA
DB-800GF 800 1000 880 1100 ISO 20ft GP
DB-900GF 900 1125 1000 1250 ISO 20ft GP
DB-1000GF 1000 1250 1100 1375 ISO 20ft GP
DB-1100GF 1100 1375 1200 1500 ISO 40ft HQ
DB-1200GF 1200 1500 1320 1650 ISO 40ft HQ
DB-1500GF 1500 1875 1650 2063 ISO 40ft HQ
DB-1600GF 1600 2000 1760 2200 ISO 40ft HQ
DB-1800GF 1800 2250 1980 2475 ISO 40ft HQ
DB-2000GF 2000 2500 2200 2750 ISO 40ft HQ
DB-2200GF 2200 2750 2420 3025 ISO 40ft HQ
DB-2400GF 2400 3000 2640 3300 ISO 40ft HQ
DB-2500GF 2500 3125 2750 3437.5 ISO 40ft HQ
DB-2600GF 2600 3250 2860 3575 ISO 40ft HQ

contact us for more product information.
