Fertilizer Crushing Equipment
Lump Breaker
Request a Quote
Lump breaker is engineered to handle the toughest size-reduction challenges. It uses high-pressure impact, squeezing, and shearing forces to break down large materials into smaller particles, making them easier to process or transport. Built with high-wear alloy components and a heavy-duty welded frame, it features hydraulic overload protection for superior impact resistance and anti-deformation. The inclusion of shock-absorbing elements, like rubber buffers and rotor counterweights, reduces vibration loss, ensuring stability and a long operational life, even in harsh conditions. This size reduction machine is designed to be highly tolerant of incoming materials, capable of directly processing large blocks of 1-1.5 meters without pre-crushing. With automatic lubrication and quick-change wear parts, it supports continuous, all-day operation for large-scale production.
Applications
The lump breaker is specifically designed to tackle the problem of crushing large materials. It plays a critical role in pre-processing materials for subsequent crushing stages in industries like mining, construction, and metallurgy. Its core function is to use immense force to break down large chunks into a manageable size.
Urea after crushing by the lump breaker
Specifications
| Model | Rotation Diameter (mm) | Input Size (mm) | Final Size (mm) | Production Capacity (t/h) | Motor Power (kW) | Reducer Model |
| | Ø600 | ≤100 | ≤50 | 5-8 | 5.5 | ZQ350 |
| | ≤150 | 10-15 | 7.5 | ZQ400 | ||
| | 15-20 | 11 |
- The shell material is Q235 steel, with the option for an internal PVC liner.
- The shaft is made of bearing steel.
On-Site Cases
Chongqing Shuangying Group, a 100,000-ton compound fertilizer production line uses our DP750 lump breaker.
Guizhou Hongfu Chemical Co., Ltd., a 100,000-ton compound fertilizer production line purchased our DP900 lump breaker.
