Self-Cleaning Melt Filter

Self-Cleaning Melt Filter
Self-Cleaning Melt Filter
Request a Quote
  • Video
    Single plate screen changer
  • Double plate screen changer

The self-cleaning melt filter is installed directly on the extruder and is used for continuous removal of impurities from the molten plastic. During operation, contaminants on the screen are removed automatically, allowing the extrusion process to run without interruption. This filter is suitable for recycling applications with high contamination levels.

Specifications
Model Power (kW) Filter Diameter (mm) Filter Mesh Single Plate Output (t/day) Double Plate Output (t/day)
350 0.75 Ø350 20-80 5-7 7-10
400 1.1 Ø400 20-80 7-10 10-20
500 5.5 Ø500 20-80 10-20 20-30
Advantages
  • Continuous filtration without stopping production, automatic cleaning allows the line to keep running, avoiding frequent shutdowns for screen replacement.
  • The filter plates are reusable, reducing solid waste and ongoing consumable costs.
  • Simple structure, and daily operation is easy to learn. Basic training is sufficient for regular use.
  • Made from durable alloy steel, the filter offers strong wear resistance and helps prevent screen damage that could lead to filtration failure.
