Screen Changer (Melt Filter)
Request a Quote
Haosu offers an economical, efficient way for plastic extrusion industry to filter almost any thermoplastic material, which can help you manage highly-contaminated materials
Screen Changer (melt filter) has applications in:
- Plastic Recycling
- Extruding
- Blowing
- Compounding
New Generation Melt Filter
(Backflush melt filter with two parallel configured screen discs)
| Type | Motor Power (kw) | Filter area (mm) | Screen mesh | (Yield)t/24h |
| 350 | 0.8 | Φ350 | 20~80 | 5~7 |
| 400 | 1.5 | Φ400 | 20~80 | 7~10 |
Continuous Screen Changer
| Type | Working stations | Filter area(mm) | Screen plate thickness (mm) | Driving method |
| 300*1 | Single | 300*300 | 420*350*60 | electric gear - hydraulic |
| 300*2 | Double | 300*300 | 420*350*60 | electric gear - hydraulic |
| 350*1 | Single | 350*350 | 450*390*70 | hydraulic |
| 350*2 | Double | 350*350 | 450*390*70 | hydraulic |
| 400*1 | Single | 400*400 | 520*450*70 | hydraulic |
| 400*2 | Double | 400*400 | 520*450*70 | hydraulic |
to provide you with quality screen changers that will lead to a more refined final product, less waste, shortened lead times and decreased costs.
