Drum Pre-Cleaner
Description
Th SCQY series drum pre-cleaner is primarily used to remove large inclusions such as straw, hemp rope, paper, clods, corn leaves, corn cobs, so as to protect subsequent equipment from failure or damage. Customers can choose the proper mesh depending on their materials’ properties, so as to attain the best separation effect.
Application
The drum pre-cleaner is suitable for the cleaning jobs of the raw materials in grain, feed processing, grain warehouse and many other industries, which can clean up wheat straw, corn leaves, hemp rope and other imputies in corn, wheat, rice, soybean and other raw materials.
Model | Power (kw) | Yield (t/h) | Motor service factor | Outline size(mm) |
SCQY63×1C | 0.75 | 20-40 | 4 | 840×1380×1799 |
SCQY90×1C | 0.75 | 40-60 | 4 | 1320×2213×2803 |
SCQY90×2C | 0.75 | 20-40 | 4 | 1320×1913×2803 |
SCQY120×2C | 1.5 | 40-80 | 4 | 1530×2600×4000 |
The drum pre-cleaner is provided with an access door to facilitate daily maintenance and examination and repair, as well as the replacement of the screen.
