One Color EVA Compression Molding Machine with Automatic Weighing
Request a Quote
Raw material : EVA
Technical Specifications
| ltem | Unit | Specifications |
| Model | 9M06 | |
| Raw material | EVA | |
| Total pressure | kg/cm | 150 |
| Layer of number | 2 | |
| Number of station | station | 6 |
| Layer distance | mm | 300 |
| Main cylinder stroke (max) | mm | 610 |
| Working pressure | kg/cm | 180 |
| Voltage | 380V 50Hz | |
| Motor power | kW | 16.4 7.2 |
| Heating method | Electric (72kW) | |
| Machine dimensions | mm | 8000* 3200*2670 |
| Gross weight | kg | 21000 |
Features
- Engineered with a unique machine body structure that ensures exceptional durability, preventing cracks or deformation in finished products.
- Centralized hydraulic control system equipped with a filter to prolong the lifespan of hydraulic components.
- Fitted with a PF150 prefill valve for rapid downward movement, enhancing production efficiency.
- Supports both semi-automatic and fully automatic continuous operation, with each function independently adjustable for flexible production.
- Utilizes internationally renowned hydraulic systems combined with advanced PC and PLC controls for precise and reliable performance.
- Features an automatic feeding system with computerized control of individual sole weights, ensuring high precision, significant labor savings, and reduced production costs.
- Incorporates a servo system for energy efficiency and reduced noise levels during operation.
