Two Color EVA Compression Molding Machine (EVA Pouring)
Request a Quote
Raw material : EVA
Technical Specifications
| ltem | Unit | Specifications | |
| Model | |||
| Raw material | EVA | EVA | |
| Number of stations | 6 | 8 | |
| Clamping force | T | 100 | 100 |
| Mold plate size | mm | 600*400 | 600*400 |
| Layer distance | mm | 500 | 500 |
| Mold height | mm | 80-180 | 80-180 |
| Motor power | kw | 16.4 | 16.4 |
| Mold heat method | Electric heating | Electric heating | |
| Heating power | kW | 72 | 96 |
| Machine dimensions | mm | 8000 x 1500 x 2100 | 10000 x 1500 x 2100 |
| Gross weight | kg | 12000 | 15000 |
Features
- Specifically designed for manufacturing two-color EVA products with high precision and quality.
- Equipped with an advanced industrial touchscreen interface, PLC program control, and easy touch adjustments for seamless operation.
- Centralized hydraulic system with an integrated oil tank filter extends the lifespan of hydraulic components.
- Combines renowned international and domestic hydraulic brands for reliable performance.
- Features a servo system for high efficiency and energy savings.
- Compact, well-organized structure ensures user-friendly operation and easy maintenance.
- Integrated safety light curtain safeguards operators during use and installation.
