Zhongtong’s 6609EV series is a premium 6-meter fully electric group bus developed for global markets. With modern business style design and a streamlined monocoque body structure, the group bus combines easy maneuverability on narrow urban roads with the flexibility to serve a wide range of passenger transport needs. Additionally, it is equipped with a quiet, high-efficiency electric drive system and standard air suspension, it delivers a refined and comfortable ride.
Designed with low-carbon mobility needs in mind, this bus is well-suited for corporate receptions, premium tourism shuttle services, group commuting, and international business transport. With zero-emission operation, lower running costs, and a design tailored for global applications, the group bus offers a practical solution for operators seeking cleaner and more efficient mobility.

Features
  • Flexible customization for different operations
    Built on a highly adaptable platform, the group bus can be tailored to different operating scenarios, helping customers develop more differentiated mobility solutions with lower time and cost input.
  • Standard air suspension for greater ride comfort
    Air suspension helps absorb road vibration and impact more effectively, improving both ride comfort and handling stability.
  • Optimized noise reduction throughout the vehicle
    Professional NVH treatment, supported by acoustic simulation analysis, helps reduce interior noise and create a quieter passenger environment.
Specifications
Model LCK6609EV Frame structure Monocoque
Motor brand/model Zhongtong E-Axle / TZ220XSZT13 Rated power (kW) 65/120
Rated/max torque (N·m) 172/360 Passenger capacity 10-19
Length (mm) 5995 Gross vehicle weight (kg) 7000
Width (mm) 2240 Front/rear overhang (mm) 1150/1545
Height (mm) 2930 Approach/departure angle (º) 18/15
Inner height (mm) 1860 Max speed (km/h) 100
Step height (mm) ≤400 Luggage compartment volume m³ 0.5
Wheelbase (mm) 3300 Steering position Left
Item Standard configuration
Frame structure Monocoque
Floor type Flat floor
Suspension type Air suspension
Front axle Disc-type brake system
Tire 215/75R17.5
Rims material Steel / aluminum
