N1 Self-Leveling Valve

N1 Self-Leveling Valve
N1 Self-Leveling Valve
Request a Quote
  • Optimized, compact design for stable and reliable self-leveling during operation
  • Factory-tested with over one million durability cycles and validated to high performance standards
Applications

The self-leveling valve is commonly used in skid-steer loaders, providing precise control of boom lifting and automatic bucket leveling, improving handling accuracy and operational efficiency.

Specifications
Max. Operating Pressure 210bar
Rated Flow 60L/min
Fluid Temperature Range -20℃~80℃
Ambient Temperature Range -20℃~80℃
Surface Treatment Nickel plated
Oil Viscosity Range ISO 20~400mm²/s
