Filter Bag
The polyester filter fabric has good chemical stability and heat resistance so it’s widely used in dust removal filtration field and can be applied in metallurgy, smelting, steel, casting, cement, quarrying and chemical industries.
Xin Huan Bao filter bags usually use terylene, PE, PP and PTFE as filter materials. We can make singeing, calendering, anti-static, water and oil repellent treatments to make our filter bags better adapt to your working environment.
| Material | Terylene + Easy dust cleaning treatment | |
| Weight | 500g/m2 | |
| Thickness | 1.8mm | |
| Air permeability | 350-500L/m2/S | |
| Breaking strength | Longitudinal | ≥1300 |
| Latitudinal | ≥1650 | |
| Elongation at break | Longitudinal | < 30 |
| Latitudinal | < 45 | |
| Breaking tensile force | 2.75mpa/min | |
| Working environment | ≤130℃ | |
| Acid resistance | Good | |
| Alkali resistance | Medium | |
| Corrosion resistance | Excellent | |
| Hydrolysis stability | Medium | |
| Aftertreatment | Singeing, shaping | |
You can directly choose form the above displayed filter bags. If you have any requirements for filter bag size, surface treatment method and other aspects, please contact us in time and Xin Huan Bao will provide you with custom service for filter bags.
If you want to customize other types of filter elements such as flame retardant fiber filtration, TORAY Nonwoven fabric filtration and antistatic cartridge filter elements, you can enter custom page, see custom instructions and provide us with necessary information.
