Radiator Leakage Tester
Request a Quote
This radiator leakage tester is specially designed for testing air tightness of automotive radiator cores.
- Testing pressure range is 50~400KPa.
- Double-station testing can raise your efficiency well.
- Interface of tester is very clear; operation is very convenient, one key operation, automatic stopping.
- Very high testing precision, measurable leakage ≤1pa/s.
- Very large memory, 100,000 units testing data can be saved and reviewed.
Main Features
- Very short test time by adopting advanced data collecting & processing technology
- Super high pressure resolution ratio, up to 1Pa
- Perfect circuit and pneumatic self-diagnosing function
- 4.3” large size LCD displayer, very clear and convenient
Technical Data
| Item | Data | |
| Measuring range | 0.2~20mL/min | |
| Differential pressure | Min. resolution | 1Pa |
| Sensor withstand pressure | 2MPa | |
| Test pressure | Min. displaying | 1kPa |
| Displaying range | 0~400kPa | |
| Time setting | Filling, balancing, leakage checking, draining separately | |
| Power source | AC 220V ±5%, 50Hz | |
| Test source (dry clean air) | 0.6MPa | |
| Working ambient temperature | 0~40ºC | |
| Storage temperature | 0~50ºC | |
| RH | Less than 80%, without dew | |
