Tubular Tripod Gin Pole
Request a Quote
Uses: For small pole erection in line construction
Notes:
1. The maximum output force of the manual winch is 5 kN
2. Use high strength aluminum alloy tube as main materials, steel parts are galvanized.
3. The safety factor is 2.5
Aluminum alloy tubular tripod gin pole with manual winch
| Item number | Model | Length (m) | Base stroke (m) | Allowable vertical load (kN) | Cross section (mm) | Weight (kg/m) |
| 03451 | LBGS120-7 | 7 | 4 | 30 | φ120 | 8 |
| 03452 | LBGS120-9 | 9 | 4.8 | 22 | φ120 | 8 |
