Auto Screen Printing Machine
Descriptions of Auto Screen Printing Machine
SFB-720, 780, 1020 series auto cylinder screen printing machine is a kind of auto flat screen press with high speed and high precision. This auto screen printing machine can be used in many kinds of printing, especially for golden colors and credit card and so on. The full oil, fresh color and stereoscopic model make the printing machine better than others.
Features of Auto Screen Printing Machine
1. It possesses user-friendly structure and is equipped with stable printing paper feeding system.
2. It is suitable for soft and medium-soft materials (Approx. 100-35g/m2).
3. Easy operation and high sensitivity: Frequency control of motor speed is monitored and controlled automatically.
4. Only one person is needed to operate the machine.
5. We can install the machine with UV dryer and stacker into an auto screen press line.
Model | SFB-720 | SFB-780 | SFB-1020 |
Max. Printing Size | 720×500mm | 780×520mm | 1020×650mm |
Min. Paper Size | 350×270mm | 350×270mm | 480×270mm |
Max. Paper Size | 720×520mm | 780×540mm | 1020×700mm |
Border | ≤15mm | ≤15mm | ≤15mm |
Paper Thickness | 100-350g/m2 | 100-350g/m2 | 100-350g/m2 |
Pallet Size | 880×880mm | 940×940mm | 1280×1140mm |
Max. Printing Speed | 600-3600s/h | 1000-3600s/h | 1000-3600s/h |
Weight | 3200kg | 3500kg | 4100kg |
Power | 7.20kw | 8.20kw | 8.20kw |
Dimensions (mm) | 3020×1400×1250 | 3020×1470×1280 | 3150×1680×1300 |
