Adhesive Label Die Cutting Machine

Adhesive Label Die Cutting Machine
Request a Quote

MQ-320 adhesive label die cutting machine can not only act as the optimal corollary equipment for rotogravure printer, continuous screen printer, flexo graphic printer and anti fake trademark molding machine, but also serve for various types of trademark factory, including polyester film type, counterfeit proof laser type as well as self adhesive paper type.

By means of plate pressing plate, our adhesive label die cutting machine possesses high precision and high efficiency. Besides, there are three photoelectric eyes in this device, which can well control the tracking and positioning on both edges and longitudinal of the web material. Meanwhile, the computer is in control of towing material and slicing. Moreover, our product can accomplish laminating, die cutting, waste collecting, slicing as well as rewinding together.

Specifications
Cutting speed 20-125times /min
Max. unwinding diameter 450mm
Max. web width 320mm
Max. die cutting width 300mm
Max. die cutting length 290mm
Orientation accuracy ±0.15mm
Total power 3kw
Power supply 220V±10%
Weight 1500kg
Overall dimensions 2600x950x1400mm
Tags
  • Label Slitting Equipment for Sale
  • Custom Die Cut
  • Label Machine

Jiangnan Enterprise is an experienced adhesive label die cutting machine manufacturer in China. Our company provides a wide range of products, including softgel encapsulation machine, capsule filling machine, granulator, tablet press machine, and more.
