Flatbed die cutter for labels and stickers

Model SAG320/450

The label die cutting machine uses an accurate flatten die-cutting system, material towing controlled by computer, and web-guiding by three photoelectric eyes. Die cutting, waste rewinding and finished-material rewinding are finished in one process.

Applications

The label die cutting machine is used for die cutting the roll type of material such as adhesive paper, Dacron label, and laser hologram mark. This is the ideal association equipment for the flexo printing machine, silk screen printing machine, gravure printing machine and hologram mark printing machine, and it's the most efficient machine for printing houses and an ideal machine for the label making industry.

Technical Specifications of the Label Die Cutting Machine
Model SAG320
Cutting speed 20-175 t/min
Max. unwinding diameter 500 mm
Max. web width 320 mm
Max. die-cutting width 300 mm
Max. die-cutting length 300 mm
Orientation accuracy ±0.1 mm
Total power 3.5KW
Power voltage 220V ±10%
Machine weight 1700kg
Machine dimensions 2600 × 990 × 1400mm

CBADEN Machinery Group is a specialized label die cutting machine manufacturer based in China. We offer label slitting machine, disposable plastic glove making machine, UV spot machine, die cutting and creasing machine, and much more.

At CBADEN, we supply an extensive range of converting & printing machines and provide comprehensive services to accommodate customer's individual production demands.
