RLF-500 Triplex Mud Pump
Specification of RLF-500 Triplex Mud Pump Item | |
Rated Power (hp/kW) | 500 (373) |
Stroke Rate (SPM) | 165 |
Stroke Length (in./mm) | 7.5"/190.5 |
Reduction Gear Ratio | 4.286 |
Suction Inlet Diameter (in./mm) | 8"/203 |
Discharge Outlet Diameter (in.) | 4" Flange 5000psi |
Valve | API5# |
Maximum Liner (in./mm) | 6-3/4"/170 |
Overall Dimension (L×W×H mm) | 3658×2709 ×2231 |
Approximate Weight (kg) | 9770 |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
φ170 | φ160 | φ150 | φ140 | φ130 | φ120 | φ110 | φ100 |
9.41365 | 10.61540 | 12.11750 | 13.92010 | 16.12335 | 18.92740 | 22.53260 | 27.23945 |
Displacement (L/S)/(GPM) |
165 | 35.67565 | 31.60501 | 27.77440 | 24.19383 | 20.86330 | 17.77281 | 14.93236 | 12.34195 |
150 | 32.43514 | 28.73455 | 25.25400 | 21.99348 | 18.96300 | 16.16256 | 13.58215 | 11.22178 |
140 | 30.27480 | 26.81425 | 23.56373 | 20.53325 | 17.70280 | 15.08239 | 12.67201 | 10.47166 |
130 | 28.11445 | 24.90394 | 21.88347 | 19.06302 | 16.44260 | 14.00222 | 11.77186 | 9.73154 |
120 | 25.94411 | 22.98364 | 20.20320 | 17.60279 | 15.17240 | 12.93205 | 10.86172 | 8.98142 |
110 | 23.78377 | 21.07334 | 18.52293 | 16.13255 | 13.91220 | 11.85188 | 9.96158 | 8.23130 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
Stroke per Minute | Liner size (in.) and P Rated Pressure (Mpa/psi) |
6-3/4 | 6-1/2 | 6 | 5-1/2 | 5 | 4-1/2 | 4 |
9.251340 | 9.971445 | 11.71695 | 13.932020 | 16.852445 | 20.813020 | 26.333820 |
Displacement (L/S)/(GPM) |
165 | 36.28575 | 33.65533 | 28.67454 | 24.09382 | 19.91316 | 16.13256 | 12.74202 |
150 | 32.99523 | 30.59485 | 26.06413 | 21.90347 | 18.10287 | 14.66232 | 11.58184 |
140 | 30.79488 | 28.55453 | 24.32385 | 20.44324 | 16.89268 | 13.68217 | 10.81171 |
130 | 28.59453 | 26.51420 | 22.59358 | 18.98301 | 15.69249 | 12.71201 | 10.04159 |
120 | 26.39418 | 24.47388 | 20.85330 | 17.52278 | 14.48230 | 11.73186 | 9.27147 |
110 | 24.19383 | 22.43356 | 19.11303 | 16.06255 | 13.27210 | 10.75170 | 8.49135 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
RLF-800 Triplex Mud Pump
Specification of RLF-800 Triplex Mud Pump Item | |
Rated Power (hp/kW) | 800 (597) |
Stroke Rate (SPM) | 150 |
Stroke Length (in./mm) | 9"/228.6 |
Reduction Gear Ratio | 4.185 |
Suction Inlet Diameter (in./mm) | 10"/254 |
Discharge Outlet Diameter (in.) | 5-1/8" Flange 5000psi |
Valve | API6# |
Maximum Liner (in./mm) | 6-3/4"/170 |
Overall Dimension (L×W×H mm) | 3963×3025 ×2410 |
Approximate Weight (kg) | 14500 |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
φ170 | φ160 | φ150 | φ140 | φ130 | φ120 | φ110 | φ100 |
13.82000 | 15.62260 | 17.72570 | 20.32950 | 23.63420 | 27.74015 | 33.04780 | 34.55000 |
Displacement (L/S)/(GPM) |
150 | 38.92617 | 34.47546 | 30.30480 | 26.39418 | 22.76360 | 19.39307 | 16.29258 | 13.47213 |
140 | 36.32575 | 32.17510 | 28.28448 | 24.63390 | 21.24336 | 18.10287 | 15.21241 | 12.57199 |
130 | 33.73534 | 29.88473 | 26.26416 | 22.87362 | 19.72312 | 16.81266 | 14.12224 | 11.67185 |
120 | 31.13493 | 27.58437 | 24.24384 | 21.11334 | 18.21288 | 15.51246 | 13.03206 | 10.77171 |
110 | 28.54452 | 25.28400 | 22.22352 | 19.35307 | 16.69264 | 14.22225 | 11.95189 | 9.87156 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
Stroke per Minute | Liner Size (in.) and Rated Pressure (Mpa/psi) |
6-3/4 | 6-1/2 | 6-1/4 | 6 | 5-1/2 | 5 | 4-1/2 | 4 |
13.561965 | 14.632120 | 15.822295 | 17.162490 | 20.432965 | 24.723585 | 30.514425 | 355075 |
Displacement (L/S)/(GPM) |
150 | 39.58627 | 36.70582 | 33.94538 | 31.27496 | 26.28417 | 21.72344 | 17.59279 | 13.90220 |
140 | 36.94586 | 34.26543 | 31.67502 | 29.19463 | 24.53389 | 20.27321 | 16.42260 | 12.97206 |
130 | 34.30544 | 31.81504 | 29.41466 | 27.10430 | 22.78361 | 18.82298 | 15.25242 | 12.05191 |
120 | 31.67502 | 29.36465 | 27.15430 | 25.02397 | 21.02333 | 17.37275 | 14.07223 | 11.12176 |
110 | 29.03460 | 26.92427 | 24.89395 | 22.93363 | 19.27305 | 15.93252 | 12.90204 | 10.19162 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
RLF-1000 Triplex Mud Pump
Specification of RLF-1000 Triplex Mud Pump Item | |
Rated Power (hp/kW) | 1000 (746) |
Stroke Rate (SPM) | 140 |
Stroke Length (in./mm) | 10"/254 |
Reduction Gear Ratio | 4.207 |
Suction Inlet Diameter (in./mm) | 12"/305 |
Discharge Outlet Diameter (in.) | 5-1/8" Flange 5000psi |
Valve | API6# |
Maximum Liner (in./mm) | 6-3/4"/170 |
Overall Dimension (L×W×H mm) | 4267×3167 ×2580 |
Approximate Weight (kg) | 18790 |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
φ170 | φ160 | φ150 | φ140 | φ130 | φ120 | φ110 |
16.62410 | 18.82725 | 21.43100 | 24.53555 | 28.44125 | 33.44840 | 34.55000 |
Displacement (L/S)/(GPM) |
140 | 40.36639 | 35.75566 | 31.42498 | 27.37434 | 23.60374 | 20.11318 | 16.90268 |
130 | 37.47594 | 33.20526 | 29.13462 | 25.42403 | 21.92347 | 18.67296 | 15.69248 |
120 | 34.59548 | 30.64485 | 26.93427 | 23.46372 | 20.23320 | 17.24273 | 14.48229 |
110 | 31.71502 | 28.09445 | 24.93391 | 21.51341 | 18.54294 | 15.80250 | 13.28210 |
100 | 28.83457 | 25.53404 | 22.44355 | 19.55310 | 16.86267 | 14.36227 | 12.07191 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
Stroke per Minute | Liner Size (in.) and Rated Pressure (Mpa/psi) |
6-3/4 | 6-1/2 | 6-1/4 | 6 | 5-1/2 | 5 | 4-1/2 | 4 |
16.352370 | 17.632555 | 19.072765 | 20.693000 | 24.623570 | 29.794320 | 355075 | 355075 |
Displacement (L/S)/(GPM) |
140 | 41.05651 | 38.06603 | 35.19558 | 32.43514 | 27.25432 | 22.52357 | 18.24289 | 14.41228 |
130 | 38.12604.2 | 35.35560 | 32.68518 | 30.12477 | 25.31401 | 20.91331 | 16.94269 | 13.39212 |
120 | 35.18558 | 32.63517 | 30.16478 | 27.80441 | 23.36370 | 19.31306 | 15.64248 | 12.36196 |
110 | 32.25511 | 29.91474 | 27.65438 | 25.48404 | 21.41339 | 17.70281 | 14.33227 | 11.33180 |
100 | 29.32465 | 27.19431 | 25.14398 | 23.17367 | 19.47309 | 16.09255 | 13.03207 | 10.30163 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
RLF-1300 Triplex Mud Pump
Specification of RLF-1300 Triplex Mud Pump Item | |
Rated Power (hp/kW) | 1300 (969) |
Stroke Rate (SPM) | 120 |
Stroke Length (in./mm) | 12"/305 |
Reduction Gear Ratio | 4.206 |
Suction Inlet Diameter (in./mm) | 12"/305 |
Discharge Outlet Diameter (in.) | 5-1/8" Flange 5000psi |
Valve | API7# |
Maximum Liner (in./mm) | 7"/180 |
Overall Dimension (L×W×H mm) | 4617×3260 ×2600 |
Approximate Weight (kg) | 24572 |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
φ180 | φ170 | φ160 | φ150 | φ140 | φ130 |
18.72712 | 213045 | 23.73437 | 273915 | 314495 | 34.55000 |
Displacement (L/S)/(GPM) |
120 | 46.54737 | 41.51658 | 36.77583 | 32.32512 | 28.15446 | 24.27385 |
110 | 42.66676 | 38.05603 | 33.71534 | 29.62469 | 25.81409 | 22.25352 |
100 | 38.78614 | 34.59548 | 30.64485 | 26.93427 | 23.46372 | 20.23320 |
90 | 34.9553 | 31.13493 | 27.58437 | 24.24384 | 21.11334 | 18.21288 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
Stroke per Minute | Liner Size (in.) and Rated Pressure (Mpa/psi) |
7 | 6-3/4 | 6-1/4 | 6 | 5-1/2 | 5 |
19.172780 | 20.652994 | 24.073490 | 26.163793 | 31.134539 | 355075 |
Displacement (L/S)/(GPM) |
120 | 45.41720 | 42.23669 | 36.20574 | 33.36529 | 28.04444 | 23.17367 |
110 | 41.63660 | 38.71614 | 33.19526 | 30.58485 | 25.70407 | 21.24337 |
100 | 37.84600 | 35.19558 | 30.17478 | 27.80441 | 23.36370 | 19.31306 |
90 | 34.06540 | 31.67502 | 27.15430 | 25.02397 | 21.03333 | 17.38275 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
RLF-1600 Triplex Mud Pump
Specification of RLF-1600 Triplex Mud Pump Item | |
Rated Power (hp/kW) | 1600 (1193) |
Stroke Rate (SPM) | 120 |
Stroke Length (in./mm) | 12"/305 |
Reduction Gear Ratio | 4.206 |
Suction Inlet Diameter (in./mm) | 12"/305 |
Discharge Outlet Diameter (in.) | 5-1/8" Flange 5000psi |
Valve | API7# |
Maximum Liner (in./mm) | 7"/180 |
Overall Dimension (L×W×H mm) | 4615×3276 ×2688 |
Approximate Weight (kg) | 24791 |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
φ180 | φ170 | φ160 | φ150 | φ140 | φ130 |
23.63345 | 25.93750 | 29.24235 | 33.24820 | 34.55000 | 34.55000 |
Displacement (L/S)/(GPM) |
120 | 46.54737 | 41.51658 | 36.77583 | 32.32512 | 28.15446 | 24.27385 |
110 | 42.66676 | 38.05603 | 33.71534 | 29.62469 | 25.81409 | 22.25352 |
100 | 38.78614 | 34.59548 | 30.64485 | 26.93427 | 23.46372 | 20.23320 |
90 | 34.9553 | 31.13493 | 27.58437 | 24.24384 | 21.11334 | 18.21288 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
Stroke per Minute | Liner Size (mm) and Rated Pressure (Mpa/psi) |
7 | 6-3/4 | 6-1/4 | 6 | 5-1/2 | 5 |
24.193508 | 25.463692 | 29.664300 | 32.164663 | 34.55000 | 355075 |
Displacement (L/S)/(GPM) |
120 | 45.41720 | 42.23669 | 36.20574 | 33.36529 | 28.04444 | 23.17367 |
110 | 41.63660 | 38.71614 | 33.19526 | 30.58485 | 25.70407 | 21.24337 |
100 | 37.84600 | 35.19558 | 30.17478 | 27.80441 | 23.36370 | 19.31306 |
90 | 34.06540 | 31.67502 | 27.15430 | 25.02397 | 21.03333 | 17.38275 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
RLF-2200 Triplex Mud Pump
Specification of RLF-2200 Triplex Mud Pump Stroke per minute | Rated Power (hp) | Liner Size (mm) and Rated Pressure (Mpa) |
φ140 | φ150 | φ160 | φ170 | φ180 | φ190 | φ200 | φ210 | φ220 | φ230 |
35 | 35 | 35 | 35 | 31 | 27.9 | 25.1 | 22.8 | 20.8 | 19 |
Displacement (L/S) |
105 | 2200 | 28.76 | 33.01 | 37.56 | 42.40 | 47.54 | 52.96 | 58.69 | 64.70 | 71.01 | 77.61 |
90 | 1886 | 24.65 | 28.30 | 32.19 | 36.34 | 40.75 | 45.40 | 50.30 | 55.46 | 60.87 | 66.53 |
80 | 1676 | 21.91 | 25.15 | 28.62 | 32.31 | 36.22 | 40.35 | 44.71 | 49.30 | 54.10 | 59.13 |
70 | 1467 | 19.17 | 22.01 | 25.04 | 28.27 | 31.69 | 35.31 | 39.12 | 43.13 | 47.34 | 51.74 |
60 | 1257 | 16.43 | 18.86 | 21.46 | 24.23 | 27.16 | 30.27 | 33.54 | 36.97 | 40.58 | 44.35 |
1 | | 0.2738 | 0.3143 | 0.3577 | 0.4038 | 0.4527 | 0.5045 | 0.5590 | 0.6162 | 0.6763 | 0.7392 |
Based on 100% volumetric efficiency and 90% mechanical efficiency |
