High-speed Stretch Film Rewinder

High-speed Stretch Film Rewinder
High-speed Stretch Film Rewinder
High-speed Stretch Film Rewinder
High-speed Stretch Film Rewinder
High-speed Stretch Film Rewinder
High-speed Stretch Film Rewinder
Request a Quote

Model: PPD-18KG
Master roll: diameter ≤500mm, width 500mm
Finished roll: max. diameter 250mm
Film thickness: 8-50 micro
Unwinding paper core diameter: 76mm (3'')
Rewinding paper core diameter: 50/76mm or customized
Max. machine speed: 1200m/min
Motor power: 4.37kW
Voltage: 220/380/415V (optional)

Applications
This high-speed rewinder is used for rapid conversion of a master roll of stretch film to several smaller rolls with same web width, suitable for stretch film roll of a range 2kg-20kg.

Features
  • Variable frequency speed control, adjustable speed 0-1500m/min;
  • Quick rewinding and roll changeover, high production efficiency;
  • Fully automatic PLC system with touch screen control panel;
  • Finished roll core diameter is available in 2inch, 3inch
  • Timing belt is adopted for low noise, high speed and long service life;
