LED Module, MSX-225B

Request a Quote

View All: http://factory-ledlighting.com/2-2-1-27-msx225b.html

Connected with flexible cables
IP rating (modules): IP67
Luminous flux per module chain: 150LM
CE marked
5-year warranty

Features:

LED modules adopt SMD2835 LEDs with high luminous efficiency up to 150lm/w, which offers low thermal resistance, spot free lighting, long lasting and good color consistency.
PC triple lenses with 170° viewing angle provide large and uniform light-emitting area
ABS plastic molded housing is waterproof and fire rate, which makes the LED module be suitable for use in indoor and outdoor environments at low and high temperatures.
Low voltage input of DC12V ensures high operation safety
Features good air tightness and an IP67 rating

Technical parameters:

Model	Input voltage	Power	Luminous flux	Color temperature	LED	Beam angle	Color
MSX225B	DC12V	0.36W/pcs	55lm	7000-8000K / 9000-12000K	2835	170°	Pure white / Cold white

Other technical parameters:

Max daisy chain（PCS）	Shell color	LED drivers	Weight (g/pcs)	Working temperature（℃）	Storage temperature	IP rating (module)	Warranty period（year）
50	White	Constant Voltage	5	-25-60℃	-25-80℃	IP67	5

Installation or wiring diagram

With light transmittance 60%, a white cast acrylic sheet with 4mm thickness is used for testing the LED module.

Dimension:

Light Distribution Curve:

Connection diagram:

Packaging

Packing: 2500pcs/bag
Size: 220*300*0.075mm
Carton size: 520*370*260mm
Net weight: 9.0(1±10%)kg
Gross weight: 9.5(1±10%)kg

Notes: The above-mentioned packaging quantity and weight are only for the illustrated packaging method, which vary from the packaging method.
The above parameters are subject to change without notice.

Installation Instructions:

The main power cable is 2x2.5mm² or longer. If longer LED Rigid Bar lines are needed, the lamp power must be selected with a wire above 1mm² / 18 # specifications in order to avoid overloading the power cord. Overloading the power cord leads to excessive heat and dangerous consequences. The switching power supply and power cord length straight between the lamp should not be longer than 3 meters. If longer, the line loss increases with an increase in total power.
Please use the connection diagram in the wiring scheme.
The screws in the lamp mounting should be inserted straight into the holes and locked into place.
When the LED Rigid Bar trails have a bare wire conductor, using diagonal pliers, first strip about 10mm of the wire, then screw it into the connection head insulation protection.
To ensure waterproofing and corrosion protection, after the power line is screwed into the terminals, we recommend an injection of a one-component silicone (or otherwise neutral glass, plastic, or waterproof grease) to cover the bare copper wire power cord for additional protection.
Do not touch the wire after it is installed, as it is a live wire.
We recommend a switching power supply with the relevant regulatory certification (short circuit protection, overvoltage protection, overcurrent protection).
