Continuous bag sealing machine for heavy-duty PE film bags
The IMS impulse sealing machine is designed for continuous and rapid sealing of heavy-duty PE film bags. Its pulse-controlled heating system allows the temperature to adjust quickly, making it suitable for fast-paced production environments.
Features
- A layer of PTFE film protects the heating tube and prevents material adhesion.
- The sealing system presses the bag firmly during sealing to improve heat efficiency, making it suitable even for powder-filled bags.
- The impulse-heating design enables extremely fast warm-up and allows the machine to begin operation almost immediately.
- When synchronized with a conveyor, it delivers continuous sealing with adjustable speed control.
- The sealing height can be adjusted, and the compact design fits easily into existing production lines. A 5 mm heating wire with protective housing provides fast sealing performance while keeping power consumption low, making it ideal for facilities that need high-speed, efficient sealing.
Technical Specifications
| Heating width | 5mm |
| Impulse control | Temperature control |
| Heating stroke | 450mm |
| Max. bag width | 550mm |
Specifications are subject to change without prior notice.
Product images may differ from the actual model configuration.
| Conveyor speed (mm/s) | Sealing time (s) | Capacity (bags/hr) |
| 6 | 3.9 | 600 |
| 8 | 2.78 | 800 |
| 10 | 2.1 | 1000 |
| 12 | 1.65 | 1200 |
| 14 | 1.33 | 1400 |
| 16 | 1.09 | 1600 |
