Double Twist Twinner with Vertical Back Twister Manufacturer

Double Twist Twinner with Vertical Back Twister

Request a Quote

View All: http://supermachinerycn.com/2-2-2-double-twist-twinner-with-vertical.html

Application

Double twist twinner with vertical back twister is applicable for LAN cable including CAT5 cable, CAT5E cable and CAT6 cable. The suitable single line twisting materials include copper, pair-wire, flexible coppers, aluminum, etc.

Effect after twisting

Internal part of the twist twinner

Twist twinner parameters

Core diameter: max Φ1.5mm
Twisting diameter: max Φ3.0mm
Pitch: 6-60mm
Rotational speed: max 2000rpm
Take-up tension: Magnetic powder clutch
Bobbin up and down: hydraulic
Diameter of take-up reel: ￠500MM

Internal part of the back-twister

Back-twister parameters

Pay-off reel diameter: Φ500MM
Rotational speed: max 1000RP
Line diameter: max Φ1.5MM
Pay-off tension: 4-40N
Reel movement: electrical
Back-twist ratio: max 60% (adjustable)

Features

Pre-back twisting beforehand, significantly improving the impact on the line materials while twisting the core wire.
The vertical back-twister save more land area compared to the horizontal back-twister, suitable for factory with smaller size.
Feedback linkage with main pay-off and the twisting machine through tension arm swinging. The linkage system will act to suspend the working equipment when any of the equipment lagging and report error to ensure safety usage.
The back twister pay-off and twist twinner is controlled by PLC control system to set the back-twist ratio with maximum 60%.
The equipment works in fully-closed situation. High efficiency and the safety of the operators is assured.
