Silicone Coated Fiberglass Sleeving
Request a Quote
CB-SGS/CB-SRS
Non-Shrink Tubing for Electronic Applications
Applications - They are widely used in insulation protection for H&N class motors, household appliances, heating equipment, special lamps, internal wiring of televisions and electronic instruments, and more.
- Silicone coated fiberglass sleeving is made by weaving alkali-free glass fiber yarn into a tube and then coating it with silicone resin through high-temperature treatment.
- Silicone rubber coated fiberglass sleeving is made by weaving alkali-free glass fiber yarn into a tube and then coating it with silicone rubber through high-temperature treatment.
- Both products exhibit superior dielectric properties, self-extinguishing properties, and flexibility.
| Raw Materials | Purpose | Content | |
| Glassfiber | SiO2 Al2O CaO3 | Insulation and temperature resistance | 50% |
| Silicone | (SiO2 )n | Insulation and voltage withstand | 50% |
| Raw Materials | Purpose | Percentage | |
| Glassfiber | SiO2 Al2 O CaO3 | Insulation and temperature resistance | 50% |
| Silicone Oil | [(CH3)2SiO]n | Insulation and voltage withstand | 50% |
| Properties | Performance |
| Continuous operating temperature | -10℃ 200℃ |
| Temperature resistance | 200℃±2℃,168H≥1/2 original voltage value |
| Heat aging | 260℃, 6 hours, no cracking |
| Cold bend | No cracking |
| Self-extinguishing time | 10 seconds |
| Horizontal burning | ≤30 seconds |
| Flammability | VW-1 |
| Volume resistivity | 1011 Ω.CM |
| Hydrolytic stability | Not sticky, no distortion, no softening |
| Model | Test Conditions | Average Voltage | Individual Value |
| | UL 1441 | 1200V | 1000V |
| | UL 1441 | 1500V | 1000V |
| | UL 1441 | 2500V | 1800V |
| | UL 1441 | 4000V | 3000V |
| | UL 1441 | 4000V | 3000V |
| | UL 1441 | 7000V | 5000V |
