G80 Special Webbing Connector
Request a Quote
Features
● It is forged by special alloy steel with high intensity and high toughness, and then it is heat treated;
● It can be matched with sling and G80 chains which can meet the standard EN818-2;
● Each workpiece should pass testing at 2.5 times of working load limit;
● We should carry out sampling and 20000 times of fatigue testing;
● We should carry out strict sampling and breakage testing for each batch of products;
● We should carry out 100% magnetic powder flaw detection;
● 100% of the pin should be tested to ensure that they have the same hardness;
● Surface treatment: plastics spraying.
● Color code: red RAL3020/yellow RAL1003.
| ITEM NO. | WEIGHT/kg | Working Load Limit (T) | Breaking Load (T) | A±1 | M±l | H±l | K±2.5 | L±3 |
| 8-SL079-19 | 3.1 | 12.5 | 50 | 37 | 26 | 20 | 186.5 | 246 |
| 8-SL079-22 | 4.55 | 15 | 60 | 48 | 28 | 25 | 205.5 | 273 |
| 8-S1079-25 | 6.1 | 20 | 80 | 51.5 | 33 | 30 | 231 | 306 |
