Low Temperature Sensor, MJZT

Low Temperature Sensor, MJZT
Low Temperature Sensor, MJZT
Low Temperature Sensor, MJZT
Low Temperature Sensor, MJZT
Request a Quote
  • MJZT-A Low Temperature Sensor
  • MJZT-B Low Temperature Sensor
  • MJZT-C Low Temperature Sensor
  • MJZT-D Low Temperature Sensor

MJZT low temperature sensor is specially designed for temperature sensing duties of air-conditioner and fridge, responsible for room temperature sensing and device interior temperature sensing. With a working temperature range of -40℃~120℃ and a wide resistance range of 0.1~500KΩ, the sensor could also be applied in water heater, water dispenser, range hood, electric kettle, goldfish bowl, food processor, etc.

Features
  • Tightly sealed for good insulation resistivity and waterproof performance;
  • Insulation resistance: ≥100MΩ;
  • Wide resistance range: 0.1~500KΩ;
  • Highly accurate resistance and B value grant high measuring accuracy;
  • Compact size, fast response and good uniformity;
  • Good stability after long-term operation, good reliability assured;
  • Working temperature: -40℃~120℃;
  • Dissipation constant: ≥ 2.0mW/℃ in still air;
  • Time constant: ≤10s (25℃~50℃, in water).
Applications
  • Working temperature: -40℃~120℃
  • Suitable wire color: black, white, red, blue, etc.
  • Major applications: air-conditioner and fridge.
  • Other applications: water heater, water dispenser, range hood, electric kettle, goldfish bowl, food processor, etc.
