Low Consistency Cleaner


ZSC series low consistency cleaner is suitablefor purifying all kinds of fiber suspension (density 0.4~1.2%). It can not only effectivelyremove impurities, hot melt materials, pulp residues, etc. from the paper pulp,but also clean foamed plastic, dust cork, ink particle and air off the pulp. Inaddition, our low consistency cleaner can screen out the coarse residue fromthe waste paper pulp, which greatly simplifies the operation procedure,thus reducing power consumption.

Our low consistency cleaner isprimarily composed of tangent stock inlet, accepts outlet, upper cylindersegment with a plug-in deaeration tube, middle cone separate tube segment, andnozzle or reject discharge control segment.

Features
1. Compared with similar products, our low consistency cleaner features longerseparate section and deaeration tube, and consequently, achieves betterefficiency.
2. It operates stably and eliminates blocking problem, resulting in consistentpulp quality.
3. This pulp cleaner is competitively priced and long lasting.
The above features have made our low consistency cleaner very popular withcustomers from
Ecuador, Egypt, Saudi Arabia, Peru,Indonesia,etc.

Working Principle
Our
low consistency cleaner is a hydrocyclonecleaner. The stock under certain pressure enters the cleaner in the tangentialdirection and generates high-speed vortex in the cone separate tube, duringwhich, the heavy impurities are thrown against the wall of the cleaner anddischarged from the nozzle or reject controller, the accepts gather at thecenter of separate tube to form main flow and discharged from the upper acceptsoutlet, and under radial pressure the light impurities and bubbles are forcedinto the center of the vortex and ejected from the plug-in tube .

Specifications of Low Consistency Cleaner

Model

ZSC41

ZSC42

ZSC43

Through put (L/min)

600

Inlet consistency ()

0.41.2

Pressure of inlet pulp (MPa)

0.20.3

Discharge pressure (MPa)

0.06

Pressure drop (MPa)

0.16

Reject ratio ()

1020

1020

1020
