Ducted Split Unit, 25kW-350kW Split Air Conditioning Unit

Request a Quote

View All: http://ruidonghvac.com/2-2-rooftop-split-air-conditioning-unit/index.html

The rooftop split air conditioning unit is an energy-efficient air conditioning system specially designed for commercial use. The air conditioner is suitable for use in hotels, supermarkets, office buildings, and many other large scale places.

Download

Technical Parameters

Air Cooled Type Unit-1

Model			RLF 30		RLF 35		RLF 40		RLF 60		RLF 70
			Side discharge	Top discharge	Side discharge	Top discharge	Side discharge	Top discharge	Side discharge	Top discharge	Top discharge
Performance	Cooling capacity	kW	28		34		39		58		68
	Power supply		3N-380V-50Hz
	Control range and accuracy		18℃~ 30℃±2℃
	Electric heater	kW	18		24		24		36		48
	Air flow	m³/h	5400		6500		7200		10000		13000
	ESP	Pa	0	80/150/300	0	80/150/300	0	100/250/400	0	100/250/400	100/200/400
	Noise level	dB(A)	64	66/67/68	64	66/67/68	64	65/67/69	68	69/71/73	81/82/83
Indoor Unit	Compressor		Hermetic scroll
			1		1		1		2		2
		kW	11.2		13.6		17.6		23.2		27.2
	Refrigerant		R407c / R22
		kg	4.8		5.8		7.5		9.9		11.6
	Control device		TXV
	Evaporator		Copper pipe with aluminium fins type
Condenser			Copper pipe with aluminium fins type
Air Supply System	Supply fan		Centrifugal fan
	Power	kW	0.75	0.75/1.5/2.2	0.75	0.75/1.5/2.2	1.5	1.5/2.2/3	1.5	1.5/3/4	2.4/4/5.5
	Filter		Nylon
Dimension	L	mm	1400		1700		1700		1900		1900
	W	mm	680		680		680		850		925
	H	mm	1980	1700	1980	1750	1980	1750	2230	1900	2000
Weight		g	310	300	370	360	460	445	530	510	870
Outdoor unit x qty			RSW-30N×1		RSW-35N×1		RSW-40N×1		RSW-30N×2		RSW-35N×2

Air Cooled Type Unit-2

Model				RLF 85	RLF 100	RLF 110	RLF 125	RLF 170	RLF 190
Model				Top discharge	Top discharge	Top discharge	Top discharge	Top discharge	Top discharge
Performance	Cooling capacity	kW		85	100	112	124	164	183
	Power supply			3N-380V-50Hz
	Control range and accuracy			18℃~ 30℃±2℃
	Electric heater	kW		48	48	54	72	90	108
	Air flow	m³/h		16000	18000	20000	22000	25000	35000
	ESP	Pa		120/300/450	120/300/450	150/350/450	200/400/500	450/550	500/600
	Noise level	dB(A)		70/72/75	70/72/75	72/74/77	75/77/79	80/82	81/82
Indoor Unit	Compressor			Hermetic scroll
				3	3	3	4	6	6
			kW	34	40	44.8	49.6	65.6	73.2
	Refrigerant			R407c / R22
	Refrigerant		kg	14.5	17.1	19.1	21.2	28	31.2
	Control device			TXV
	Evaporator			Copper pipe with aluminium fins type
Condenser				Copper pipe with aluminium fins type
Air Supply System	Supply fan			Centrifugal fan
	Power	kw		4/5.5/7.5	5.5/7.5	5.5/7.5	7.5/11	11/15.0	15/18.5
	Filter			Nylon
Dimension	L	mm		2200	2200	2200	2200	2350	3344
	W	mm		1025	1025	1300	1300	1590	1541
	H	mm		1800	1800	1950	1950	2050	2050
Weight		g		990	1230	1590	1650	1700	2150
Outdoor unit x qty				RSW-30NC×3	RSW-40NC×3	RSW-40NC×3	RSW-40NC×4	RSW-60NC×3	RSW-60NC×3

Features

We provide various types of rooftop split air conditioning units for different specifications to meet various domestic or commercial demands. We devote ourselves to provide a comfortable and pleasant environment for our clients.
The complete air purifier system is easy for cleaning and convenient for maintenance. Remove the screw from any side of the air conditioning unit to access the components of the air conditioner.
