Dehumidifier Unit, 25kW-350kW

Request a Quote

View All: http://ruidonghvac.com/2-5-dehumidifier-unit/index.html

The dehumidifier unit is for humidity control often used in conjunction with refrigeration or air conditioning units. These dehumidifiers are particularly useful in textile production, food processing, server farms, and libraries.

Download

Technical Parameters

RFC Type Dehumidifier Unit-1
Unit model		RCF	5	10	15	20	25	30	40	50
Dehumidification qty		kg/h	5	10	15.6	20.8	25	31	41	49
Cooling capacity		kW	8.5	16.9	26.4	35.2	42.3	52.4	69.3	82.8
Input power		kW	2.2	3.9	6.3	9.0	10.6	12.5	17.3	20.7
Power			3N-380V-50HZ
Refrigerant			R407C/R22
Compressor type			Hermetic scroll
Indoor unit	Air flow	m³/h	1500	3000	4000	6000	7000	9000	11000	13000
	ESP	Pa	50	50*/230	50*/230	50*/230	50*/230	50*/230	300	350
	Input power	kW	0.25	0.4*/0.7	0.7*/1.5	0.8*/1.5	1.3*/2.2	1.3*/3	3	4
Unit Dimension	L	mm	700	900	1300	1300	1700	1700	1900	1900
	W	mm	600	600	700	700	700	800	850	900
	H	mm	1900	1950*/1650	2150*/1850	2250*/1950	2250*/1950	2250*/1950	2250	2250
Unit weight		kg	110	190	280	370	440	630	720	870
Remarks			1. Standard working condition DB 27℃，WB21.1℃
Remarks			2. *means front air supply unit with louver

Features

Dehumidifier unit is composed of a heating type, temperature adjusting type and cooling type.
The cooling dehumidifier unit can refrigerate the environment while dehumidifying, but refrigeration function can't be adjusted. These are applicable for places with large thermal loads and no requirement for relative humidity.
Closed scroll type compressor, with excellent liquid impact resistance performance.
Main types include exhaust fan without air hose connected, exhaust fan with air hose connected, no exhaust fan but with air hose connected.
