Sweeper Truck with High Pressure Washer
Description:
This sweeper truck with high pressure washer can be used alone as street sweeper for cleaning and suctioning the road and as high pressure washer for washing the road, as well as can be used as sweeper truck for selective combination purpose of road sweeping, suctioning and washing to satisfy different clients’ needs.
This sweeper truck with high pressure washer is widely used for high cleanness cleaning and common cleanness cleaning the road surface, kerb, kerb vertical plane, overpass, square and airport, etc.
This sweeper truck with high pressure washer can offer clients nine different types of operation mode. At the same time, this sweeper truck with high pressure washer provide a efficient and environmental cleaning method for cleaning the city, sweeping the overpass and collecting the dust on the road.
| Base Plate Model | DFH1180BX1V | Machine Model | ESN5180TXS | Absorption Rate | ≥96％ |
| Base Plate Motor Model | ISD210 50 | Maximum Sweeping Width | 4.1m | Maximum Total Weight | 18000kg |
| Emission Standard | National V | Sweeping Width on the Road | 3.5m | Volume of Solution Tank | 9m³ |
| Rated Power/RPM | 155kw/2500rpm | Sweeping Speed | 3-15km/h | Volume of Waste Container | 7m³ |
| Discharge Capacity | 6.7L | Rated Pressure for Cleaning Water | 12mpa | Maximum Size of Absorbed Granule | 100mm |
| Gearbox Model | DF6S900 | Rated Flow for Cleaning Water | 137L/min | Dimension (Length*Width*Height) | 8720*2490*3020mm |
| Drive Axle | 10T Single Stage Final Drive, Final Ratio: 5.571 | Sweeping Width | 3.5m | Approach Angle | 20° |
| Tire | 1000R20 18PR Radial Tire | Sweeping Speed | 3-15km/h | Departure Angle | 14° |
| Volume of Fuel Tank | 160L | Cleaning Speed | 3-20km/h | Minimum Ground Clearance | 180mm |
| Wheel Base | 5000mm | Maximum Sweeping Capacity | 70000m²/h | ||
| Total Weight | 18000KG | Discharging Angle | ≥48° | ||
| Drive Method | 4*2 Rear Wheel Drive | Low Pressure Sweeping Width | 24m |
- Multiple Functions: Capable of road cleaning, high pressure cleaning, dust falling by watering, road washing and sweeping, etc.
- Safety Protection: Multiple alarm settings like water shortage alarm, water overflow alarm enable the sweeper truck with high pressure washer to be more safe.
- High Cleaning Rate: Deeply cleaning the road to achieve the effect that the road is suitable for sitting.
- Intelligent System: Equipped with one key control system for easy and accuracy operation.
- Centralized Operation: The two wide suction nozzles are internally equipped with centralized high pressure water spray rod for centralized operation.
- Self-cleaning: The trash bin is capable of self-cleaning.
