Elbow Making Machine SBWT-1000

Elbow Making Machine SBWT-1000
Request a Quote

This elbow making machine is primarily for making round duct elbows as it locks both female and male components together to form a tube elbow. It meets basic needs for production of elbow parts and features a geared motor. This means the speed is non-variable and has a little lower precision compared to a hydraulic elbow making machine.

Parameter:
Type SBWT-1000 SBWT-1500 SBWT-1000A SBWT-1500A SBWT-1000D SBWT-1500D
Max Diameter Of Elbow 1.2 mm 1.5mm 0.4-1.2mm (galvanized steel ) 0.4-1.0mm (stainless steel) 0.4-1.8mm (galvanized steel ) 0.4-1.2mm (stainless steel) 0.4-1.2mm (galvanized steel ) 0.4-1.0mm (stainless steel) 0.4-1.8mm (galvanized steel ) 0.4-1.2mm (stainless steel)
Diameter Range φ120-1150mm Φ120-1500mm φ120-1000mm Φ120-1500mm φ120-1000mm φ120-1500mm
Forming Speed 35r/min 35r/min 75r/min 75r/min 75r/min 75r/min
Motor Power 1.5KW×2 2.2KW*2 1.5kw*2 2.2KW×1 2.2KW*2 4kw*1 1.5kw*2 2.2KW*2 2.2KW*2 4KW*2
Weight 600Kg 700Kg 600Kg 660Kg 600kg 660kg
Dimension 2080×720×895mm 2450×700×895mm 2100×700×890mm 2450×700×895mm 2080×700×895mm 2450×700×895mm
