On-Board Battery Charger
Request a Quote
The on-board battery charger is a DC charging device mounted inside the electric vehicle, and transfers an AC input into a DC output to supply a reliable charge to your EV.
The on-board charger is designed with a wide DC output range of 200VDC-450VDC, 250VDC-650VDC and 300VDC-750VDC (adjustable) to meet various voltage and charging requirements.
The on-board charger allows users to charge their electric vehicle so long as there is a reliable power socket, because it is a movable charging pile that features a compact structure, an excellent cooling performance, and outstanding insulation effects.
Applications
Applicable for all types of electric vehicle on-board DC charging.
Advantages
- Wide input voltage range: 90V-264V, designed with input surge protection, and each charger module has power of 3.3kW, 6.0kW or 20kW
- The system uses DSP (digital signal processing) control technology, and is 100% numerically controlled from input to output
- Input THDI < 3%, input power factor reaches 0.99 and overall efficiency reaches 95% and above;
- Wide output voltage range: 200-750VDC (adjustable): suitable for meeting different charging requirement voltage demands
- Low DC ripple causes minimal effects on battery lifespan
- Standard CAN communication interface configuration allows for easy data transferring with external devices.
- The on-board battery charger is equipped with input overvoltage protection, undervoltage alarming, output overcurrent and short circuit protection functions;
- The on-board battery charger is equipped with a 13.8VDC auxiliary power supply to support the BMS (battery management system).
Technical parameters
Model | VRM360P20000W | VRM360P6000W | VRM360P3200W | |
System capacity | 20kW | 6.0kW | 3.3kW | |
Input voltage | 220Vac/380Vac | 220Vac | 220Vac | |
Range of input voltage | 90-264VAC; 90-175VACoutput power derating 50% | |||
Input frequency | 50/60HZ | |||
Input power factor | 0.99 | |||
Input THDI | ≤3% | |||
Overall efficiency | ≥95% | |||
Output voltage | 200VDC-450VDC / 250VDC-650VDC / 300VDC-750VDC | |||
BMS auxiliary power supply | 13.8VDC/7.5A | |||
Output voltage tolerance | <0.5%(13.8VDC<1%) | |||
Output current tolerance | <1% | |||
Peak to peak noise voltage of DC output | <1% | |||
Startup & shutdown overshoot | <10% | |||
Soft start time | 5S | |||
Operating temperature | -40℃~65℃ | |||
Storage temperature | -40℃~70℃ | |||
Operating humidity | 5%-95%, 40±2℃, non-condensing | |||
Altitude range | 4000 m | |||
Dimension (W*D*H)mm | 415*460*110 | 280*460*110 | 280*350*110 | |
Heat dissipation method | Air cooling/liquid cooling | |||
Protection level | IP67 |
