Concrete Block Pre-cutter
Concrete cutting machine for removing the side waste of concrete cake with two wires
The pre-cutter includes a concrete block wire cutting machine and a concrete block trimming machine. These machines trim the surface of the concrete cakes, making the appearance smoother and more aesthetically pleasing.
The concrete block wire cutting machine is used to trim the appearance of the concrete cake before cutting, ensuring dimensional accuracy. Its primary function is to trim the top and bottom surfaces of the blocks, removing uneven parts from the surface. This equipment is easy to operate and has adjustable speed. The automatic cutting process not only ensures high production efficiency but also improves the dimensional accuracy of the concrete cakes.
Specifications
- Model: HDAS-002
- Dimensions: 2500×1500×2100mm
- Power: 10kW
- Speed: 30m³/h
The concrete block trimming machine is used for trimming the side surfaces of the concrete cake. It features fully automated control and is easy to operate. The fully automatic operation simplifies the demoulding process and reduces time, saving labor and improving dimensional accuracy.
Specifications
- Model: HDWE-002
- Dimensions: 8100×2700×2550mm
- Power: 28kW
- Speed: 30m³/h
