E-Liquid Filling Machine, DTNX-60E
E-Liquid Cartomizer Filling Machine, E-Liquid Bottle Filling Machine, E-Juice Bottle Filling Line, E-Liquid Filling and Capping Machine
This equipment is applicable in the auto liquid filling and capping lines for small volumes of plastic/glass bottles. With the filling steps preset by micro-computer, the system adopts peristaltic pump (ceramic pump for some special circumstances) to accomplish the filling process with a certain liquid volume. This e-liquid bottle filling machine combines the operations of bottle feeding, filling, plug inserting, capping, and discharging together, and has been widely applied in many industries like pharmacy, daily chemical, chemical engineering, and food.
Features
1. The peristaltic pump for filling has made bottle cleaning and product switching rather convenient (ceramic pump or glass pump is used for special conditions)
2. The adoption of back-suction filling method allows for no leakage
3. Users are able to set the filling volume or do some fine adjustment without stopping the machine
4. The filling, plugging or capping process will stop if the bottles are absent
5. The automatic e-liquid filling machinery features adjustable capping torque
6. Laminar flow hood is available upon request
7. It is in line with GMP standards
8. Auto alarming function
Technical Parameters
Filling volume: 2-30ml (others are customizable)
Production capacity: 40-60 bottles /min or 80-120 bottles /min
Measuring deviation: <±1%
Speed control: variable frequency control
Compressed air pressure: 0.4-0.8 MPa
Power supply: 220V 50Hz
Power: 1.2kw
Weight: 650Kg
Dimension: 2400×1000×1600 mm
Applications
Zhonghuan automatic e-juice bottle filling machine has been applied widely in e-cigarette liquid, eye drops, reagents, among other products
