Flexible Duct Connector Machine

Request a Quote

Website: http://rollforming-line.com/2-flexible-duct-connector-machine.html

RLJ-1 Flexible Duct Connector Machine for HVAC System

This flexible duct connector machine is used to produce connector rolls for ventilation systems. It is capable of forming rectangular flexible duct connectors and includes a notching function for M8 holes.

Technical Data

• Galvanized steel strip thickness0.4-0.7mm
• Galvanized steel strip width50-140mm
• Fireproof fabric strip width100-300mm
• Final production strip width140-540mm
• Main motor power3kW
• Hydraulic station power7.5kW
• Servo motor power0.75kW
• Speed0-10m/min
• Machine size3000 x 1500mm
• Weight2500kg
