TIG Tube Mill, Stainless Steel Tube Mill

Request a Quote

View All: http://pipemakingmachines.com/2019/2-tig-tube-mills.html

TIG tube mills are stainless steel tube production equipment that utilizes a TIG (tungsten inert gas welding) method. Tubes produced using this equipment feature a diameter range of Ф6～Ф219mm with maximum wall thickness of 4mm.

The TIG tube mill is made up of 9 main components, which, listed in order are:

Uncoiler
Forming machine
Welding machine
Grinding machine
Sizing machine
Straightening machine
Cutting machine
Run-out table
Pipe collection

We also have a special design model for chimney pipe manufacturing. Specifications for this are in the last row of the parameter table.

Technical Parameters

Model	Pipe OD. (mm)	Wall Thickness (mm)	Dia. Of Horizontal Axis (mm)	Dia. Of Vertical Axis (mm)	Main Motor Capacity	Machine Size (L*W)
SS 25mm	Ф6-Ф25	0.2-0.8	30	25	4KW	19.5m*1.0m
SS 32mm	Ф6-Ф32	0.2-1.0	40	25	5.5KW	20m*1.0m
SS 51mm	Ф9-Ф51	0.2-1.5	40	25	7.5KW	21.5m*1.1m
SS 64mm	Ф12-Ф64	0.3-2.0	40	25	11KW	21.5m*1.1m
SS 76mm	Ф25-Ф76	0.3-2.0	50	30	11KW	24m*1.2m
SS 114mm	Ф38-Ф114	0.4-2.5	60	40	15KW	26m*1.4m
SS 168mm	Ф76-Ф168	1.0-3.5	80	50	18.5KW	32m*2.3m
SS 219mm	Ф114-Ф219	1.0-4.0	100	60	22KW	36m * 2.5m
Chimney Pipe	Ф60-Ф100	0.3-1.0	50	30	11KW	25m*1.2m

Each production line is strictly designed and made according to customer requirements, and we are dedicated to providing the best line for specific customer needs. Please do not hesitate to reach out to us for more information.
