ERW273 electric resistance welded carbon steel pipe production line

Product & Yield Round Pipe 114mm-273mm Thickness:3.0mm-10.0mm
Square & rectangle tube 90mm×90mm -210mm×210mm Thickness:3.0mm-8.0mm
Length 6m-12m Length Tolerance: ±3mm
Production Speed 20-45 m/min
Production capacity 40,000ton/year
Consumption Mill installed capacity 350 kw
Line Area 120m(length) ×10m (width)
worker 6-8 workers
Raw Material Carbon Steel coil Carbon steel coil Q235B(ASTM GR·D,σs 230)
Width 280mm-690mm Thickness: 2.0mm-8.0mm
Coil ID 570-640mm
Coil OD Max. 1800mm
Coil Weight 15.0t
Advantages
  • Rolls cost roughly 60% less than other comparable products.
  • One set of rollers is capable of pipe production in a variety of sizes using direct square forming technology.
  • Electric control and automatic adjustment reduce roller changing time in an accurate, fast manner.
