Chain Driven Live Roller Conveyor (CDLR Conveyor)
Conveyor system for pallet handling
Chain driven live roller conveyor (CDLR conveyor) is a conveying system that uses rollers to horizontally transport unit loads in a continuous operation. Each individual CDLR unit is driven by a single motor, with the rollers connected by a loop chain, enabling long-distance transportation and material accumulation to enhance line efficiency. This equipment can be tailored in length, width, roller spacing, and other aspects to suit specific requirements. The CDLR conveyor boasts broad versatility, robust driving force, a simple structure, and easy maintenance.
Chain driven live roller conveyor is suitable for transporting various materials carried on pallets.
EV battery, automated warehouse logistics, tobacco and alcohol industry, e-commerce retail, pharmaceuticals and food, automotive and construction materials, etc.
- Utilizes roller retainer guide.
- Channel steel frame is 125x50x4mm in size.
- Built-in motor
| Parameter | |
| Length mm | 910≤L≤5760 |
| Width mm | B 134 |
| Effective width B mm | 820≤B≤1420 |
| Height H mm | H≥350 |
| Motor Brand | SEW, NORD, CPG |
| Chain Brand | ZIQIANG CHAIN, CHOHO |
| Color | Powder coating with all RAL colors available. |
| Nonstandard models can be customized. | |
| Product Information | ||
| Basic Information | Load Capacity | ≤1500kg |
| Speed | 12, 16, 18m/min | |
| Temperature | 5℃ to 45℃ | |
| Relative Humidity | ≤90% (No condensing) | |
| Roller | Roller Diameter | Ø60, Ø76, Ø89 |
| Roller Drive | Steel double sprocket | |
| Installation | Internal thread | |
| Drive Mode | Drive Motor | Gear motor |
| Motor Power | 0.37, 0.55, 0.75, 1.1kW (beaked motor is available) | |
| Motor Voltage | 380V | |
| Brake Voltage | 220V | |
| Drive Method | Chain | |
| Installation | Ground Installation | Expansion bolts |
| Ground Flatness | Level ground, error ≤5° | |
| Height Adjustment | ±30mm | |
