Fiber Distribution Box
Request a Quote
We provide fiber distribution boxes that are suitable for small capacity communications systems. These boxes feature compact structures and can handle wall mounting.
The fiber distribution box is divided into two parts. One is linked with optical cables for fusion connection between the optical cable and fiber pigtail and the other links with a patch cord.
Both fusion and storage functions are compatible with optical cables.
The protective design of the cabinet ensures the fiber cables have a bending radius of ≥40mm
Fiber protection accessories are provided to avoid unexpected damage
Features- Indoor application
- Fiber splice, optical splitter, cable storage
- Max. Capacity: 72 fibers
- Can be customized
| Model | Size(mm) | Capacity (core) | Note |
| KWMSB-D /A-24 | 455*405*80 | 24 | The case body is made of cold rolled steel with electrostatic spraying making it suitable for outdoor wall mounting. we provide 24-72 adaptors that are available for SC/ST/LC |
| KWMSB-D /A-48 | 455*405*120 | 48 | |
| KWMSB-D /A-72 | 455*405*150 | 72 | |
| KWMSB-D /B-48 | 455*405*120 | 48 | |
| KWMSB-D /B-72 | 455*405*150 | 72 | |
| KWMSB-D /A-24A | 350*350*80 | 24 | |
| KWMSB-D /C-FC12 | 350*300*80 | 12 | |
| KWMSB-D /C-SC12 | 350*300*80 | ||
| KWMSB-D /D-FC24 | 350*300*80 | 24 | |
| KWMSB-D /D-SC24 | 350*300*80 | ||
| FSP-72A | 550*480*120 | 72 | |
| FSP-32B | 360*345*100 | 32 | |
| FSP-16C | 400*385*110 | 16 | |
| FSP-16B | 320*270*100 | 16 | |
| FSP-16A | 360*345*100 | 16 |
